| DC to DC (Mosfet)SSR input Specification |
| MODEL OF SSR |
Type |
801 |
802 |
806 |
807 |
808 |
707 |
| Input control supply voltage |
VDC |
3-32 |
3-32 |
3-32 |
3-32 |
5/12/24 |
3-32 |
3-32 |
3-32 |
3-32 |
3-32 |
3-32 |
3-32 |
| Input control supply current |
mA |
4-16 |
4-16 |
4-16 |
4-16 |
8 |
4-12 |
4-12 |
4-16 |
4-16 |
4-16 |
4-16 |
4-16 |
| Input max. Impedance |
Ohm |
1.5k ohms |
470/1.5k/3.3k |
1.5k 0hms |
1.5k ohms |
1.5k 0hms |
| DC to DC (Mosfet) SSR Output Specification |
Continuos Drain current at 20°C
with heat sink |
Amp |
100 |
15 |
25 |
14 |
14 |
14 |
14 |
8 |
4 |
200 |
50 |
28 |
Safe continuos rating Id at
55°C with heat sink |
Amp |
70 |
9 |
18 |
8 |
2 |
3 |
8 |
4 |
2 |
140 |
36 |
16 |
Drain-to-source break down
voltage Vdss (BR) |
VDC |
55 |
200 |
200 |
500 |
100 |
100 |
100 |
200 |
500 |
55 |
200 |
500 |
| Minimum holding current |
mA |
20 |
20 |
20 |
40 |
1 |
3 |
3 |
20 |
20 |
80 |
80 |
80 |
Static drain-to-source ON
resistance rDS (ON) |
Ohm |
0.004 |
0.085 |
0.042 |
0.13 |
0.115 |
0.023 |
0.023 |
0.18 |
0.85 |
0.002 |
0.021 |
0.0675 |
| Power dissipation pd @
TC-25'C |
W |
300 |
190 |
380 |
560 |
56 |
200 |
200 |
125 |
125 |
600 |
720 |
368 |
| Pulsed Drain Current |
IDM |
780 |
120 |
240 |
146 |
56 |
230 |
230 |
70 |
30 |
1560 |
480 |
292 |
| Peck diode recovery dv/dt |
V/ns |
5 |
8.6 |
8.6 |
3.5 |
7.1 |
5.8 |
5.8 |
5 |
5 |
5 |
8.6 |
3.5 |
| Max. Off set leakage current |
mA |
5 |
5 |
5 |
5 |
- |
- |
- |
5 |
5 |
5 |
5 |
5 |
| Drain-to-source leakage Current Idss |
mA |
10 |
10 |
10 |
10 |
1 |
1 |
1 |
10 |
10 |
10 |
10 |
10 |
Maximum Junction
Temperature Tj(max) |
°C |
175 |
150 |
150 |
150 |
150 |
150 |
150 |
150 |
150 |
175 |
150 |
150 |
Thermal resistance junction
to
case Rthjc |
°C/W |
0.5 |
0.45 |
0.225 |
0.225 |
2.7 |
1 |
1 |
1 |
1 |
0.25 |
0.11 |
0.11 |
Load Voltage drop less than At
Rated Current |
Vds |
1.2 |
1.3 |
1.5 |
1.7 |
0.4 |
0.4 |
0.4 |
1.5 |
2 |
2 |
2.2 |
2.4 |
| Turn ON Delay Time Td-ON |
mS |
1 |
1 |
2 |
1 |
2.5 |
1 |
1 |
1 |
1 |
2.5 |
2.5 |
2.5 |
| Turn Off Delay Time Td-OFF |
mS |
1 |
1 |
2 |
1 |
2.5 |
1 |
1 |
1 |
1 |
2.5 |
2.5 |
2.5 |
| Duty Cycle (100%) |
|
1 |
1 |
1 |
1 |
1 |
1 |
1 |
1 |
1 |
1 |
1 |
1 |
| Isolation Voltage |
Kva |
4 |
4 |
4 |
4 |
1.5 |
1.5 |
1.5 |
2.5 |
2.5 |
4 |
4 |
4 |
| Square Wave Output |
Hz |
1K |
1K |
500 |
1K |
400 |
400 |
1K |
1K |
1K |
400 |
400 |
400 |
| Electrical connection wire size |
O/p |
16sqmm Lugs |
|
plug in Type Pin |
Plug in
Type Pin |
Plug in
Terminal 1.5 sqmm |
4sqmm Lugs |
25 sqmm Lugs |
| I/p |
4sqmm Lugs |
|
4sqmm Lugs |
4sqmm Lugs |
