2 Wire - DC(Namur) Inductive Sensors
Range of 2 wire-DC(Namur) Sensors:- Screwed Type

Sr.#
Model No.
Dimensions
Sensing
Range mm
O/P Logic
Sensor Head
Mounting
IDNO13
BEE4052-310-14-4240
40x40x112
13
NO
Front
IDNO14
BEE4052-310-14-4240
40x40x112
13
NC
Front
IDNO15
BEE4052-310-14-4340
40x40x112
13
NO
Top
IDNO16
BEE4052-301-14-4340
40x40x112
13
NC
Top
IDNO17
BEE4052-310-14-4440
40x40x112
13
NO
Right
IDNO18
BEE4052-310-14-4440
40x40x112
13
NC
Right
IDNO19
BEE4052-310-14-4540
40x40x112
13
NO
Left
IDNO20
BEE4052-310-14-4540
40x40x112
13
NC
Left
IDNO21
BEE4052-310-14-4640
40x40x112
13
NO
Adjustable
IDNO22
BEE4052-310-14-4640
40x40x112
13
NC
Adjustable
Sr.#
Termination
Load Current
mA
Operating
Frequency Hz
Visual Indication (LED)
IDNO13
Screwed Terminals
400
100
Red & Green
IDNO14
Screwed Terminals
400
100
Red & Green
IDNO15
Screwed Terminals
400
100
Red & Green
IDNO16
Screwed Terminals
400
100
Red & Green
IDNO17
Screwed Terminals
400
100
Red & Green
IDNO18
Screwed Terminals
400
100
Red & Green
IDNO19
Screwed Terminals
400
100
Red & Green
IDNO20
Screwed Terminals
400
100
Red & Green
IDNO21
Screwed Terminals
400
100
Red & Green
IDNO22
Screwed Terminals
400
100
Red & Green
Dimensional Drawings for 2 wire - DC (Namur) Sensors:- Screwed Type

IDNO 3050, ID 3052, ID 3054, ID 3056
Pages: 1 2
